TurboFarmer 38.10

MODEL FEATURES:

The TF38.10 comes as standard with the EPD TOP version: this electronic control gives the possibility to vary engine rpm directly with the joystick and to activate the Eco and Speed Control functions, in order to maximize ease of use, performance and above all to reduce fuel consumption.
Heavy Load function, on the other hand, allows the machine's full potential to be exploited in the most demanding contexts, making it particularly useful for those who carry out heavy excavation work.

• This model comes with the new ASCS system (Adaptive Stability Control System) in Full version. This tool allows ensuring the maximum operational safety of the machine in any condition and with any TreEmme attachments. It offers a 10.1” colour screen and it allows:
• Displaying the capacity diagram, updated in real time
• Setting and managing the geometric limits of machine use
• Setting and adjusting the maximum speed of hydraulic movements
• The premium cab gives easy access, astounding space with great visibility: generous in dimensions, the cab is mounted on Silent Block, which drastically reduce vibrations, guaranteeing maximum comfort and visibility, whist the option of Cab Suspension provides a superior ride unique to Merlo.


This machine comes as standard with:


• Engine: Deutz 3.6 Stage V 105kW/ 143hp
• Transmission: Hydrostatic EPD
• Hydraulic system: Load Sensing 150 l/m 250 Bar
• Capacitive Joystick
• Reversible fan
• Tractor homologation
• Pick up hitch
• Electric socket for trailer
• Hydraulic braking
• Front and rear diff lock
• Continuous Oil delivery
• Fork Jack Guards
• Superior Cab configuration
• Sun shade
• Double rear hydraulic line with selector and proportional control
• LED lights on cab
• Lights on boom
• Roof wiper
• Rear mirror
• 405/70-24 tyres

Performance

Everything at your fingertips

Exclusive precision:

Guarantees maximum movement precision, thanks to the hydrostatic transmission, which ensures millimetric variations in the machine's movements and load's positioning.

Compact and lightweight:

The Merlo telescopic handlers are compact and lightweight to reduce manoeuvring space and impact on the ground. These features guarantee safety, manoeuvrability, productivity and lower consumption.

Visibility:

Merlo telescopic handlers are designed to offer the best visibility on the market, ensuring faster and safer operations.

Comfort

The best workplace

Quiet and comfortable:

The new cab, of generous dimensions (1.010 mm), is mounted on Silent Blocks, which drastically reduce vibrations, guaranteeing maximum comfort and maximum visibility for the operator.

Quick accessories changeover:

The Tac-Lock system for hydraulic clamping of the attachments further improves operating comfort.

Protection of the handled load:

The boom suspension system (BSS) is available as an option, which protects the load during transfer and maintains a high level of driving comfort on rough terrain.

Air Conditioning System:

The air flow is distributed homogeneously within the passenger compartment and optimally reaches all areas for first-class comfort.

Safety

Not just feelings

Record-breaking safety:

The Merlo integrated safety system controls the operating parameters in real time, allowing the operator to work in peace.

Certified cabs / Certified protection:

The Merlo cab is FOPS - Level II - and ROPS certified, to guarantee a high level of safety for the operator.

Efficiency

Simpler and smarter

Simple and precise operations:

The entire range is equipped with hydrostatic transmission, which makes the work phases simpler and more precise. Moreover, the dry disc brakes limit the absorption of energy, thereby reducing the machine’s fuel consumption.

Fan Drive:

The Fan Drive is a technology fitted as standard that allows you to change the engine fan's rotation direction from venting, which cools the radiators, to blowing, which cleans the radiators, eliminating dust and residues collected during the work phase.

Reduced consumption: The exclusive Eco Power Drive (EPD) technology automatically controls and adjusts the engine revolutions based on operating conditions. As a result, the engine speed is disconnected from the accelerator pedal.

This technology achieves a reduction in fuel consumption of up to 18%.
