NEUWERTH Logistics SA - Mitsubishi Forklift Trucks - PBR20N - Pallet truck

PBR20N

Stand-up Power Pallet truck, Long distances, small spaces... no problem!

For long distance (over 50 metres) transport and transfer of goods, as well as loading and unloading, you should give your operator the comfort, security and ergonomic benefits of a stand-on or sit-on powered pallet truck.

With powerful acceleration, fast travel and optimum operator efficiency, you will soon see a major increase in throughput.

Narrow chassis

Compact machine offers optimal driver protection whilst maintaining the minimum machine footprint (500 mm less than a conventional platform power pallet truck). Allows handling of Euro and CHEP pallets.

Excellent all-round visibility

Combining the elevated driver platform with very small chassis provides exceptional fork-to-tip vision for fast, safe, precise pallet handling, reducing damage. This design also allows for increased storage.

Robust forks with pallet entry rollers

Strong, welded fork construction with large bearing sizes maximises reliability and longevity, so the truck will operate in the toughest applications.

Battery rollers

This feature allows for easy battery maintenance and exchanges to deliver maximum uptime.

Strong fully-welded forks

Robust fork construction offers long, trouble-free operation.

Reference PBR20N

Manufacturer Mitsubishi Forklift Trucks

Model PBR20N

Load capacity 2000 kg

Lowered mast 1365

Forks 50 / 165 / 1150

Type of drive control stepless

Axle no load 220 / 660

Tire type Vulcollan

Service weight 2880 kg

Load center distance 600 mm

Length 1915

Width 790

Rear tread 457

wheelbase 35

AST 800x1200 2189

Speed with/without load 8/11 km/h

Lifting with/without load 0.03/0.04 m/s

Tire size, front 250 × 100 mm

Gradeability with/without load 6/15 %

Service brake electric

Axe full load load 1800 / 1080

Turning radius 1750

Lowering with/without load 0.07/0.02 m/s

Typ of operation Standing

Tire size, rear 85 × 75 mm

Power unit Battery

Front Tread 375-495

AST 1000x1200 2396

Wheelbase 1525 mm

With a range that includes over 150 different models, distinctive green trucks can be seen on work sites and in warehouses all around the world - with Mitsubishi forklifts, reach trucks, order pickers, pallet trucks and more all serving the backbone for some of the busiest and demanding operations around.

Innovative design, cutting-edge technology and uncompromising quality are standards that define everything we do.

Move the world forward

Mitsubishi Forklift Trucks is proud to be part of Mitsubishi Logisnext Europe (MLE).

MLE is part of the global Mitsubishi Logisnext group - Mitsubishi Logisnext Co. Ltd (ML) - based in Kyoto, Japan. Founded in 1937, ML is a leading provider of innovative logistics and materials handling solutions, operating in Africa, the Americas, Asia, Europe, the Middle East and the Pacific. ML aims to support and contribute to society through pioneering advances in hardware and software.

ML is a component of the Mitsubishi Heavy Industries group. MHI was established in 1884, having been originally founded as a shipbuilding company in 1870 by Yataro Iwasaki. MHI has since built on its engineering heritage to become a global leader in manufacturing dedicated to continuing progress through technological advancement. It delivers integrated solutions to meet industry needs on land, at sea, in the air, and in space.

NEUWERTH Logistics SA represents the Mitsubishi Forklift Trucks in Switzerland after having commercialized the UniCarriers trucks and before the ATLET brand.
