    PALIFT TZX 170 Spider aerial platform

    • Lift Height: 17m
    • Side Offset: 7.8m
    • Max. Load capacity: 200kg

    Available with Bi-Energy (Diesel + AC) or ECO (DC + AC)

    • Model 170C = on wheels
    • Model 170R = on tracks
    Request a quote



    CHÂSSIS EN ALUMINIUM ET CENTRE DE GRAVITÉ BAS POUR UNE STABILITÉ MAXIMALE

    La double flèche télescopique articulée améliore l'agilité aérienne et offre des positions de travail stables. Le centre de gravité bas confère à la machine une excellente stabilité sur les terrains accidentés et les pentes.

    ALUMINIUM FRAME AND LOW CENTRE OF GRAVITY FOR MAXIMUM STABILITY

    The double articulating telescopic booms improves the aerial agility and offers stable working positions. The low centre of gravity gives the machine excellent stability when driving on uneven ground and slopes.

    MANUAL STABILIZERS SET-UP

    Stabilizers can be set-up anywhere thanks to the manual mode. Really useful when working in areas where precise or individual control is needed.

    2 SET-UP POSITIONS

    This model provides two distinct set-up positions: wide and narrow, to adapt the machine to suit different site requirements.

    FREEDOM OF INDOOR AND OUTDOOR USE

    Thanks to the dual power in the bi-energy version, the platform can be used both outdoor, using the diesel engine, and indoor, with zero emissions, using single-phase (powered by domestic power) or three-phase electric motors.

    POWER OPTIONS FOR EVERY NEED

    This platform is available in bi-energy version (standard) with diesel engine and electric motor; in hybrid version with diesel engine and batteries, ideal for working in closed environments where there’s no access to electricity; in ECO version, completely ecological and with zero emissions, equipped with electric motor and batteries, indoor environments or where diesel engine use is not permitted. Lead-acid or lithium batteries are both available.

    AGILITY AND COMPACTNESS

    The excellent weight / performance ratio and the small size, make this platform Palazzani Spider ideal for aerial working in places inaccessible to other types of MEWP. The ability to drive on any type of terrain, automatic chassis leveling and set-up even on slopes makes it even more versatile and suitable for use in hostile places.

    BASKET 140x70x110 cm: EASY TO REMOVE AND COMPLETE OF 230 V SOCKET

    Basket made of aluminum with a minimum capacity of 120 kg and a maximum of 230 kg, with standard dimensions of 140x70x110 cm fastened to the arm by quick coupling, easily dismantled when needed for narrow passages. Fixed control panel on the basket for all aerial maneuvers. 230V electrical outlet in the basket to use tools during the aerial work.

    WIRE CONTROL

    Cable control connected to the main panel, to perform all the maneuvers of the platform from the ground.

    ATTACHEMENTS FOR THIS MODEL:

    • Intercom
    • Additional stabilizer pads
    • Radio control
    • Anti-collision kit for basket
    • Non-marking tracks
    • Anemometre
    • Additional protections
    • Additional hoses air/water
    • Autmatic levelling system
    • 2nd speed kit
    • "Return to home" function
    TZX 170 C/R
    1500 mm
    1400 x 700 mm
    1700 mm
    7800 mm
    980 mm
    Diesel+AC (Bi-energy) or DC+AC (Eco)
    31% (C) / 25% (R)
    200 kg
    4470 mm
